Type BU (uncut) and BG (cut)
Rectangular cross section. For static and dynamic use. Reciprocating and rotating movements possible. Material: PTFE. Back-up Rings are installed together with Trelleborg O-Rings and Quad-Ring® Seals to prevent extrusion in applications above 5 MPa / 725 psi. Available in spiral, cut, or uncut designs in unfilled PTFE, based on ISO 3601, AS 568.
Size Range:
8 mm to 210 mm
Temperature:
-200 °C to 260 °C
Pressure (max):
25 MPa
Material Information for the product(s) on this page
PT00
Colour:
White to Offwhite
Basic Material:
PTFE
Commercial Description:
Unfilled PTFE. This material is standard for back-up rings. Unfilled PTFE helps prevent extrusion in low- to medium-duty applications where an O-ring used by itself would not be suitable.
PT008
Colour:
White
Basic Material:
PTFE
Hardness:
55 (Shore D)
Commercial Description:
Unfilled PTFE. This material is standard for back-up rings. Unfilled PTFE helps prevent extrusion in low- to medium-duty applications where an O-ring used by itself would not be suitable.
