Turcon® Variseal® M2S
The Trelleborg Turcon® Variseal® M2S is a single acting seal with scraper lip, based on the design of the Variseal® M2, consisting of a U-shaped seal jacket and a corrosion resistant V-spring. The asymmetric seal profile works well even in media with high viscosity and the Turcon® material and V-spring makes it compatible with a wide variety of fluids and chemicals.
Size Range:
10 mm to 250 mm
Temperature:
-70 °C to 300 °C
Pressure (max):
20 MPa
Speed (max):
15 m/s
Material Information for the product(s) on this page
T40SM
Basic Material:
PTFE/metal
Filler:
Virgin PTFE compounded with carbon fibre
Commercial Description:
Turcon® T40 is a carbon-filled PTFE material commonly used in applications where a low-lubricating hydraulic fluid is used. This material is often used in high-freqency and short stroke applications. Because of the surface texture of this material, it is best used for sealing liquids as opposed to gases. Comes with a stainless steel spring.
